XenonStrobe X401-19-01 24vDC (Pol.) AMB

IP65 10/7,5 Joule (single/double flash)

Varenr:
X401-19-01
X401-19-01 Moflash X401-19-01-AMBER XenonStrobe X401-19-01  24vDC (Pol.) AMB IP65 10/7,5 Joule (single/double flash)
X401-19-01 Moflash X401-19-01-AMBER XenonStrobe X401-19-01  24vDC (Pol.) AMB IP65 10/7,5 Joule (single/double flash)
Lenker: | DataSheet | Manual
X401 Industrial Xenon Beacons

Product overview:
The X401/400 DIN Base Series utilises a discharge capacitor and converter circuit to ignite xenon gas inside a tube, resulting with a flash of light. Xenon gas ignites virtually instantaneously so maximum brightness is obtained immediately. Xenons have an added advantage of low current consumption combined with a reasonable life span. The X401/400 Series provides a 360 degree light ouput and has a Single Flash or Double Flash option. The Double Flash option extends the signal duration making it more noticeable to the human eye. Brightness is increased by the use of a Dioptric (Fresnel) lens which magnifies the light output.This series also incorporates both bottom and side entry cabling access and mounting is achieved via external three point fixing.


Features:
Continuously rated
Suitable for surface or wall mounting
Single or double flash option
M20 side or bottom cable entry
Optional wall bracket & protective guard available - see accessory page
360° visibility
IP65


PRODUCT SPECIFICATIONS:
Nominal Voltage:       24VDC
Current Consumption: 1,45 Amp (Single Flash) / 0,7 Amp (Double Flash)
Flashes per min.:         60 FPM (Single Flash) / 90 FPM (Double Flash)
Ingress protection:      IP65
Housing material:         UV Stable Black ABS Plastic Base
Lense material:            UV Stable Polycarbonate Lens
Cable entries:               2 x M20 (side and bottom)
Operating temperature: -25°C...+55°C
Weight:                        0,82 kg
